Biomass Briquetting Equipment

BX Drum Chipper

Chipping Equipment
Basic info:
Drum chipper is a kind of special chipping machine which is used to product wood branches and wood blocks into chips, specifically, commonly used in particle board, fibreboard and paper mills and other industrial production and stock preparation section in wood manufacturing facility. Small drum chipper is the best raw material preparation plant laboratory equipment.
Main raw materials for chippers include cutting trails, logging residues (branches, twigs, etc.) and wood processing residues of raw materials (slab, slab, core logs, veneer waste, etc.), and non- agro waste raw materials (such as sugar cane, reed, bamboo, etc.) can be put into drum chipper as well.
BX Series Chippers offered by KMEC feature compact structure, easy operation, high productivity, wide adaptability of raw materials, cutting wood of high quality in a safe, reliable way, and drum chippers are also of easy maintenance, to be the more advanced chipping equipment.



Technical parameters
Table 1:
Model Check power f(N) Ring degree of single belt h(mm) V-belt type-length V-belt rollers
BX-215 58.96 17.3 5V-3353 5
BX-216 63.2 21.2 5V-4064 5
BX-218 66.7 22.4 SPC-4500 6
BX-2113 102.4 32.3 SPC-6300 8

Table2:
Model Machinable area (cm2) Machinable max. dia. of wood (cm)
BX-213 ≤75 ≤9
BX-215 ≤86.5 ≤10.5
BX-217 ≤86.5 ≤12
BX-218 ≤200 ≤16
BX-2113 ≤420 ≤23

Note: Near the maximum cross section, the cutting length is not more than 2m. Raw materials used for chipping should not be too moist or even wet.
